Meyer Integrated X-Ray Inspection Machine for Bulk Materials
Latest innovation — integrated X-Ray inspection machine for bulk material handling. Combines X-Ray technology with efficient material inspection. Suitable for detection of nut, peanut, pulses, seeds and other bulk products.
Description
▾
The Meyer 120XS4 AI is Meyer's most advanced integrated X-Ray inspection machine for bulk material handling. It combines deep learning AI technology with ultra high-definition X-ray imaging, Full Spectrum Lighting, Maglev® 3.0 ejectors, and the Sniper System — all in a single integrated unit with built-in material handling. Designed for high-volume processing of nuts, peanuts, pulses, beans, seeds and bulk food products, the 120XS4 AI delivers pixel-level defect classification down to just 1-2 pixels. The AI core continuously learns and adapts to varying material characteristics — improving detection accuracy across diverse product batches over time. Available exclusively in India through NICPL — authorized Meyer dealer with 20 years of experience and 1000+ installations across India.
Key Benefits:
Deep Learning AI Core trained to analyze complex product data in real time
Pixel-level defect classification down to just 1-2 pixels accuracy
Multi-feature data analysis combining color, shape and X-ray density simultaneously
Extensive trained model library for accurate classification of defects and contaminants
Adaptive material recognition — improves accuracy across diverse product batches over time
Detects glass, metal, ceramic, stones and dense foreign particles inside bulk products
Identifies internal defects — worm-eaten, hollow and unripe nuts invisible to naked eye
Ultra High Definition UHD imaging system capturing maximum detail per frame
Integrated X-ray and material handling in one single unit — no separate conveyor needed
Maglev® 3.0 ejectors operating at 1200 Hz for millisecond-level precise ejection
Sniper System uses 3D reconstruction to locate exact center of contamination
Full Spectrum RGB lighting reveals true material color for enhanced defect detection
Sorter power 2.5 kW — energy efficient operation at full production speed
Operates at 180~240V 50Hz with compressed air at 0.6~0.8 MPa
Dimensions 2530x1450x2500 mm — integrated compact footprint for production floor
24×7 after-sales support from NICPL — on-site installation and operator training included
Live product trial available at NICPL Trial Centre, Kundli, Sonipat
FSSAI compliant batch-wise scan records saved automatically for full traceability
What products is it suitable for?
▾
Beans
→
INPUT
✓
ACCEPT
✕
REJECT
Technical Specifications
▾
| Specification | XS Integrated AI |
|---|---|
| Sorter model | 120XS4 |
| Sorter code | MY8060-120XS |
| Sorter power (kW) | 2.5 |
| Sorter voltage (V) | 180～240 50Hz |
| Sorter air pressure (MPa) | 0.6～0.8 |
| Sorter air consumption (m³/min) | 0.3 |
| Sorter dimensions (L x W x H) | 2530x1450x2500 |
| Sorter weight (kg) | 780 ~ 850 |
| Indian Dealer | NICPL |
Features
▾
🍳 AI Powered System
📸 Ultra high-speed HD Imaging System
👁️ Innovative Vision Systems
📸 Normal vs UHD Camera
🚅 High-Speed Turning Operation
⏏️ Maglev Ejectors® — By MEYER
🌈 Full Spectrum Lighting System
🔫 Sniper System — By MEYER
💻 X-ray Inspection System
AI Powered System
- 🧠 Deep Learning AI Core — Devices are equipped with deep learning AI systems trained to analyze and interpret complex product data in real time.
- 🎨 Multi-Feature Data Analysis — Integrates multiple data features such as color and shape to build a complete profile of each product passing through.
- 📚 Extensive Model Library — Compares incoming materials against an extensive library of trained models to classify defects and contaminants accurately
- 🔍 Pixel-Level Defect Classification — Capable of precise classification of the smallest defects, down to the level of just 1-2 pixels
- 🔄 Continuous Technology Research — MEYER thoroughly researches and advances AI technology to consistently deliver the best possible sorting solutions
- ⚙️ Adaptive Material Recognition — Learns and adapts to varying material characteristics, improving classification accuracy across diverse product batches
- 🏭 Foundation for Smart Sorting — Forms the intelligent backbone of the sorter, working alongside imaging and ejector systems for precise, automated quality control
Pre and After-Sales Service
▾
PRE-SALE
Consulting solution service
Configuration suggestion
Layout suggestion
HELP DESK
Remote troubleshooting
Remote machine adjusting
Fault de-escalation
ON-SITE
Routine inspection
Commissioning
Troubleshooting
SPARE PARTS
Spare parts supply
Warranty service
Key parts maintenance
TRAINING
Local training
HQ training
Standard warranty
🌟 Pre-Sale Service — NICPL
Consultation on selecting the optimal inspection system for your product
Support integrating with your existing production lines
Product testing available — attend and observe live at Kundli
🔧 After-Sale Service — NICPL
On-site service with quick response times across India
Warranty including free inspections and maintenance
24×7 support — call +91 70115 54903 anytime
Frequently Asked Questions
▾
What is the key difference between the 120XS4 standard and 120XS4 AI model?
The 120XS4_AI uses a deep learning AI core that compares incoming materials against an extensive library of trained models, analyzing color and shape data in real time. This allows it to classify defects down to the level of 1-2 pixels, well beyond what rule-based or manual inspection can achieve.
What contaminants and defects can the Meyer 120XS4 AI detect?
The 120XS4 AI detects glass, metal, ceramic, stones, and dense foreign particles as well as internal product defects including worm-eaten nuts, hollow seeds, and unripe or damaged kernels all invisible to the naked eye and undetectable by conventional color sorters or metal detectors.
How does the AI Powered System work in the 120XS4?
The AI system integrates multiple data features including color, shape, and X-ray density to build a complete profile of each product. It compares incoming materials against an extensive library of trained models to classify defects accurately in real time forming the intelligent backbone of the entire sorting process alongside the imaging and ejector systems.
What is UHD imaging and how does it improve detection?
The 120XS4 AI features an Ultra High Definition imaging system capturing significantly more detail per frame than standard cameras. This allows the AI to detect the smallest surface and internal defects at pixel level — even in fast-moving bulk material — without slowing production throughput.
What products is the Meyer 120XS4 AI suitable for?
The 120XS4 AI is designed for high-volume bulk food products including nuts, peanuts, pulses, beans, seeds, and similar granular materials. It is ideal for rice mills, dal mills, nut processing units, grain processing facilities, spice units, and food packaging companies across India.
What are the technical specifications of the Meyer 120XS4 AI?
Key specifications are as follows — Power: 2.5 kW, Voltage: 180～240V 50Hz, Air Pressure: 0.6～0.8 MPa, Air Consumption: 0.3 m³/min, Dimensions: 2530 x 1450 x 2500 mm, Weight: 780～850 kg, Sorter Code: MY8060-120XS, Indian Dealer: NICPL.
. What is the Maglev® Ejector and why is it important in the AI model?
The Maglev® 3.0 ejector operates at over 1200 Hz frequency using magnetic levitation for non-contact, wear-free ejection. When the AI system identifies a defective or contaminated product, the Maglev ejector removes it in milliseconds with surgical precision — ensuring neighboring good products are never accidentally ejected, minimizing material loss completely.
Can I test the 120XS4 AI on my own product before purchasing?
Yes. NICPL operates a dedicated Trial Centre at Kundli, Sonipat, Haryana where you are welcome to bring your own product samples for a live inspection demonstration. This allows you to see the AI detection performance on your specific material before making any purchase decision. Contact NICPL at +91 70115 54903 or WhatsApp to schedule your trial visit.
What pre-sale and after-sale support does NICPL provide?
NICPL provides complete support at every stage — pre-sale includes consultation, configuration suggestion, layout planning, and live trial at Kundli. After-sale includes on-site installation, commissioning, operator training, remote troubleshooting, breakdown support, spare parts supply, warranty service, and 24×7 support at +91 70115 54903.
How do I get a quote for the Meyer 120XS4 AI from NICPL?
Contact NICPL through any of these channels — Website: nicplmeyer.com → Get Quote, Call: +91 70115 54903, Visit: Plot 206, Phase 2, HSIIDC, Kundli, Sonipat, Haryana 131028. Our team responds within 24 hours with a customized quote based on your product, volume, and facility requirements.
