All Series
ASD · BSD · CSD · CSDX · DSD — All 17 Models
Select a series from the sidebar filter to see specific model details. Download full technical specifications below.
18.5–132
kW
Motor Power
2.63–25.15
m³/min
Flow Rate
91–888
CFM
Flow Rate
7.5–15
bar
Pressure Options
Key Advantages
Modular Design
Compact modular construction allows flexible installation. All service points are easily accessible, reducing maintenance time and operational downtime significantly.
Integrated Refrigeration Dryer
Factory-integrated T-version dryer with +3°C dew point delivers dry, clean compressed air right out of the box — no separate dryer installation needed.
Exceptionally Quiet
Soundproofed housing reduces operational noise to a minimum. Models from 65 dB(A) — suitable for noise-sensitive industrial environments.
SIGMA PROFILE Airend
SIGMA PROFILE rotors require approximately 10 to 20 percent less energy than conventional rotors of the same air delivery capacity — saving money every day.
SIGMA CONTROL 2
Traffic-light LED indicators, 30 selectable languages, Ethernet, RFID reader, SD card slot. Fully automatic monitoring and control with multiple control modes.
Low Life-Cycle Costs
Optimal efficiency, easiest operation, service-friendliness and a global service network ensure the lowest total cost of ownership over the machine's lifetime.
Technical Specifications
Get Full Technical Specifications
Download the complete specification sheet for all 17 ASD · BSD · CSD · CSDX · DSD models —
including working pressure, FAD, CFM, dimensions, weight, sound level and more.
Working Pressure (bar)
FAD & CFM
Motor Power (kW)
Dimensions & Weight
Sound Level dB(A)
Refrigerant & Dryer
🔒 Your information is safe — we never share your data with third parties
Equipment Details
⚙️ Complete Unit▼
- Ready-to-run, fully automatic operation
- Modular soundproofed housing — compact footprint
- Vibration-damped mounting on all models
- All panels powder-coated for durability
- For ambient temperatures up to +45°C
- Easy access to all service points — removable panels
- DSD series: Dual-airend tandem design for maximum output
🔩 Rotary Screw Airend▼
- Single stage with cooling fluid injection for optimal rotor cooling
- Genuine KAESER screw compressor airend with the SIGMA PROFILE
- SIGMA PROFILE rotors require 10–20% less energy than conventional rotors
- Precision aligned roller bearings ensure long service life with maximum reliability
- DSD series: Two airends in one compact housing for flows up to 888 CFM
🔋 Electric Motor▼
- IE3 Premium Efficiency motor — quality German manufacture
- IP 54 / IP 55 protection class
- Insulation class F for greater power reserve
- V-belt drive with automatic belt tensioning — consistent efficiency
- Optional IE4 super-premium efficiency motor available
❄️ Efficient Cooling System▼
- Dual flow fan with separate air flow channels for motor, cooler and control cabinet
- Honeycomb air intake filter for maximum dust protection
- Pneumatic inlet and venting valves
- Cooling fluid separator tank with triple separation system
- Pressure relief valve and minimum pressure check valve
- Thermostatic valve and fluid filter in coolant circuit
- Energy-saving radial fan on larger models — meets EU Directive 327/2011
💧 Integrated Refrigeration Dryer (T Version)▼
- CFC-free R 134a refrigerant — all models
- Pressure dew point +3°C on all T versions
- Electronically-controlled condensate drain (ECO-DRAIN)
- Refrigerant compressor with energy-saving, cycling shut-down feature
- Fully insulated, hermetically sealed refrigerant circuit
- Hot gas bypass control for stable dew point
- Dryer power: 0.8 kW (ASD/BSD/CSD), 1.1–1.2 kW (CSDX), 2.1–2.35 kW (DSD)
🎛️ SIGMA CONTROL 2▼
- "Traffic-light" LED indicators show operational status at a glance
- Easy-to-read display with 30 selectable languages
- Soft-touch icon buttons — intuitive operation
- Fully-automatic monitoring and control
- Dual, Quadro, Vario and Continuous control modes available as standard
- Interfaces: Ethernet — standard
- Optional: Profibus DP, Modbus, Profinet and DeviceNet
- SD card slot for data logging and firmware updates
- RFID reader for secure access control
- Integrated web server for remote monitoring
♻️ Heat Recovery (Optional)▼
- Optionally available with integrated heat recovery system
- Plate-type heat exchanger for hot water generation
- Up to 96% of compression energy can be recovered as useful heat
- Reduces heating costs significantly — payback typically within 1-2 years
More Specificities
SIGMA Profile Airend
10–20% less energy than conventional rotors. Precision aligned roller bearings for long service life and maximum reliability.
SIGMA CONTROL 2
Smart controller with traffic-light LEDs, 30 languages, Ethernet, RFID reader, SD card, web server and multiple control modes.
IE3 / IE4 Motors
Premium efficiency German-made motors. IP54/IP55 protection. Optional IE4 super premium efficiency for maximum energy savings.
Integrated R 134a Dryer
Factory-fitted refrigeration dryer with ECO-DRAIN. Stable +3°C dew point. Energy-saving cycling shut-down when compressor is idle.
Low Noise Operation
Soundproofed modular housing. ASD starts at 65 dB(A), BSD 69–71, CSD 67–72, CSDX 72, DSD 68–71 dB(A).
Compact Footprint
Modular construction maximises air output per floor area. ASD fits in 1770×900 mm. DSD dual-airend in 3310×1730 mm.
Auto Belt Tensioning
Automatic belt tensioning device ensures consistent transmission efficiency and excellent drive system reliability throughout service life.
+45°C Ambient Rating
Designed for Indian climate conditions — operates reliably in ambient temperatures up to +45°C without performance loss.
Heat Recovery Ready
Optionally available with integrated plate-type heat exchanger. Up to 96% energy recovery for hot water generation and space heating.
Ready to Order a Kaeser Compressor?
Our experts will recommend the best model for your exact air demand, pressure and application
